NPT Forged Steel Gate Valve

NPT forged steel gate valve, manufactured by Waits, provides reliable fluid control solutions for your pipeline system. We were originally established in the United States, and later set up a branch in China. Our global headquarters is located in Wenzhou, China. Our production base is complete and advanced, and we can provide factory-advantage prices and stable delivery. This valve can be used in a variety of working conditions and is especially popular in the Middle East and North America.

Send Inquiry

Product Description

Compared with cast steel parts, forged steel parts have higher quality, which is reflected in the impact force they can withstand, plasticity, toughness and other mechanical properties. The general diameter of NPT forged steel gate valve is not more than DN80, and most of them are reduced diameter designs. The flow rate is slightly smaller than that of cast steel gate valves of the same diameter, but the pressure and temperature range they can withstand are higher than those of cast steel valves, and the sealing performance is much better than that of cast steel gate valves, with a longer service life, and the medium flow direction is not restricted like other gate valves.

Implementation Standards

Design Standard	API 602, GOST
Flange standards	SW Socket welding ends according to ASME B16.11, BW butt end by ASME B16.25, NPT threaded connectors according to ASME B1.20.1
End Connection	NPT
Inspection & Test	API 598
Face to Face	ASME B16.10, GOST
Pressure and temperature levels	ASME B16.34
Low leakage standards	ISO 15848-1, API 622
Anti-corrosion design	NACE MR 0103, NACE MR 0175

Application

Size	1/4"-3", DN6-DN80
Pressure Rating	Class 150-2500, PN10-PN420
Operating Temperature	-60°C~450°C
Application range	Tap water, sewage, construction, petroleum, chemical industry, food, medicine, textile, electricity, shipbuilding, metallurgy, energy system, etc.
Operator	HW, Electric, Pneumatic
Body Material	Carbon Steel, Stainless Steel, Duplex Stainless Steel, Alloy Steel, Monel, Al Bronze, etc.
Valve plate/valve seat	A105, A350 LF2, A182 F5, F11, F22, A182 F304 (L), F316 (L), F347, F321, F51), Alloy 20, Monel
Valve stem	F6A F304 F316 F51 F53 Monel K500...
Valve stem nut	Copper alloy...
Packing	Flexible graphite, graphite asbestos packing, polytetrafluoroethylene...

Performance Features

1. NPT forged steel gate valve is forged, and there are three types of cavity seals:
Bolted bonnet means that the valve body and bonnet are connected by bolts and nuts, and the wound gasket is sealed. Metal rings can also be used for connection according to customized requirements.
Welded bonnet means that the valve body and bonnet are connected by threads and fully welded. If customized, full welded connection can be used.
The 900lb, 1500lb, and 2500lb cavities adopt a pressure self-tightening sealing structure, and the sealing performance increases with the increase of internal pressure, with high reliability.
2. The channel is smooth, the flow coefficient is small, and the sealing surface is less eroded and eroded by the medium.
3. The sealing surface is made of alloy steel or hard alloy, which has good wear resistance and abrasion resistance.
4. The packing is made of flexible graphite, which is reliable and flexible to operate.
5. The flow direction of the medium is not restricted, and there is no disturbance or pressure reduction.
6. The packing replacement and maintenance can be carried out in the state of online shutdown without affecting the operation of the system.
7. Simple shape, short structure length, good manufacturing processability and wide application range.
